Parameters

Unit

Reference Information

Work mode

Multimode

Single mode

Operating wavelength

nm

850 or 1310 ±40

1250~1650

Insertion loss

dB

≤1.5

≤1.3

PDL

dB

≤0.2

Crosstalk

dB

≥35

≥50

Return loss

dB

≥30

≥45

Fiber type

-

50/125um or 62.5/125um MMF

Corning SMF-28e

Switching time

ms

≤10

Power handling

mW

500

Durability

Cycles

107

Operating temperature

°C

-5~+45

Storage temperature

°C

-20~+60

Relative humidity

%

20~90(Non-condensation)

Power supply

-

AC90~250V, 50~60Hz, 20W (Desktop)

DC 5V, 2A (Module)

Communication interface

-

RS232/USB/LAN

Dimensions (L×W×H)

mm

360×250×110/360×300×110 (Desktop)

150×145×68 (Module)

SW-1-2-3-4-5-6-7

1

Package

M=Module

D=Desktop

-

-

-

2

Fiber type

S=SM fiber

P=PM fiber

M5=50/125um

M6=62.5/125um

-

3

Input channel count

1=1 channel

2=2 channel

-

-

-

4

Output channel count

1=1 channel

2=2 channel

4=4 channel

8=8 channel

xx=Customize

5

Wavelength

85=850nm

13=1310nm

15=1550nm

13/15=1310&1550nm

-

6

Input connector

FA=FC/APC

FU=FC/UPC

SA=SC/APC

SU=SC/UPC

NA=None

7

Output connector

FA=FC/APC

FU=FC/UPC

SA=SC/APC

SU=SC/UPC

NA=None
