Parameters	Unit	EDFA / YDFA / EYDFA	SOA
Operating wavelength	nm	1040/1550	750 ~ 1650*
Saturation output power	dBm	23(EDFA/YDFA), 33(EYDFA)	12
Gain	dB	10~30	15~25
Noise figure (typ)	dB	6	9
Output power stability	dB	0.2 (Within 8 hours)
PDG (typ)	dB	0.5
Input / output optical isolation	dB	＞30
Return loss	dB	＞40
Input / output fiber type	-	SM fiber or PM fiber
Operating temperature	°C	10 ~ +40
Storage temperature	°C	-20 ~ +70
Display	-	Input and output power level, TEC temperature, etc
Electric interface	-	RS-232, LAN or USB
Power supply	V(AC)	AC90~250V, 50~60Hz, 20W (Desktop and Rackmount)
		DC 5V, 2A (Module)
		483×385×44(19” 1U Rackmount)
Dimensions  (L×W×H)	mm	360×250×110 / 360×300×110 (Desktop)
		90×70×19/100×80×19 /150×125×33(Module)

* For the specific operating wavelength range please contact our sales.

OA-1-2-3-4-5-6-7-8-9
1	Amplifier type	E=EDFA	Y=YDFA	EY=EYDFA	S=SOA	-
2	Package	M1=90×70×19	M2=100×80×19	M3=125×150×33	D=Desktop	1U=1U rackmount
3	Wavelength	850=850nm	1060=1060nm	1310=1310nm	C=C band	L=L band
4	Max gain	10=10dB	20=20dB	30=30dB	37=37dB	-
5	Max output power	05=-5dBm	0=0dBm	10=10dBm	23=23dBm	30=30dBm
6	Control type	P=APC	G=AGC	C=ACC	-	-
7	Application	B=Booster amplifier	L=Inline amplifier	P=Pre-amplifier	-	-
8	Power adjustable	1=With	0=Without	-	-	-
9	Connector	FA=FC/APC	FU=FC/UPC	SA=SC/APC	SU=SC/UPC	NA=None
